Storage Calculator

How to Use This Calculator?

This storage calculator is intended to be used for the Turing Smart Series IP cameras. It is designed for the user to enter H.265 parameters for the main stream, with a fixed H.264 sub stream.

Instructions

  1. Recording Days Need: Enter the retention period (In Days) needed for "Recording Days Needed"
  2. Motion %: Enter the estimated amount of motion to be recorded. This will affect the Normal and Event (Event, Motion, Alarm) recording types.
  3. Max Total Events per Hour: Estimated maximum total number of events per hour at the site
  4. Total Number of Concurrent Vision Clients: Estimated number of clients using Vision at the same time.
  5. Recording Type:
    Normal: Recording based on Normal Recording and Event Recording storages
    Event (Event, Motion, Alarm): Recording based on Event Recording and the Motion %.
  6. Brand: Choose between Turing or Custom brands. With Turing brands, the resolution, frame rate and pixel resolution are pre-determined. For Custom brands, you will need to enter those values yourself.
  7. Resolutions: Choose the resolution of the camera’s main stream
  8. Frame Rates: Choose desired frame rate of the camera.
  9. After resolution and frame rate have been selected, the calculator automatically gives suggested H.265 Main Stream bit rate and estimates HDD needed based on that.
  10. Enter the Quantity of the cameras that will use these video encoding parameters
  11. Use more rows to add other types of cameras using different encoding parameters.
  12. Once everything has been entered, the estimated total HDD needed is shown plus a separate amount with 10% tolerance can be found.
  13. In addition, the Upload Bandwidth Requirement and Total Cameras are also shown
  14. While programming your NVR and cameras, make sure to change Encoding parameters according to the Pixels, Frame Rate, and Recommended H.265 Main Stream Bit Rate used in the Calculator

STORAGE & UPLOAD BANDWIDTH CALCULATOR

Normal Recording Event Recording
Brand Resolution Frame Rate Pixels Main Stream
H.265 Bit Rate (Kbps)
Frame Rate Main Stream
H.265 Bit Rate (Kbps)
Quantity Sub Stream
H.264 Bit Rate (Kbps)
HDD Needed

BANDWIDTH CALCULATION DETAILS

Live View
Channel Stream Max Bandwidth (KB) Total Bit Rate Usage
1 Main

4 Sub 768 3072
8 Third 256 2048
16 Third 256 4096
Max Bit Rate Kbps
Mbps
Playback
Max Single Channel Kbps
Mbps
AI Event Upload
Approximate Event Size 2048KB
Bit Rate Needed Kbps
Mbps
